Trailer: CIMC 2 axle flatbed trailers for sale
Load capacity: 40ton to 60ton
Working platform length: 40ft
Application:carry 20ft or 40ft container
Advantage: customized produce
CIMC Flatbed trailer is another commonly used type of equipment in the transportation industry. CIMC 40 Foot Flatbed trailers are used to deliver products like pipe, steel, lumber, heavy equipment , and any other item that would be difficult to load into the back of a trailer.
CIMC production the 2 axle flatbed trailers accessories are used famous brands, such as: the axles adopts Fuwa / Bpw or othe Chinese famous brand;Landing gear adopts JOST brand and so on.Due to we used the high strengh steel to production the flatbed semi trailer ,the flatbed trailer CIMC produce is deeply loved by foreign customers.
We can provide difference configurations of CIMC 40 Foot flatbed trailer to meet your transportation requirement.
CIMC 40 Foot Flatbed Trailer
CIMC 2 axle flatbed trailers for sale
Overall L*W*H: 12,500×2,500×1,530 mm
Payload: 60 tons
Axles: 13 tons / 14 tons / 15 tons /16tons / 20 tons ( Fuwa/BPW /CIMC or other Chinese famous brand )
Tire: 12.00R20 / 11.00R20 / 12R22.5 / 385/65R22.5, optional
Landing gear: JOST
Kingpin: 50(2inch)#or 90(3.5inch)# bolted type
Suspension Mechanical: / airbag / bogie suspension
Brake system: WABCO brake system with dual brake chambers and emergency brake valve
Container lock: 12 pcs
Accessories: Tool box , spare tire carrier
1>We adopt premium steel material, advanced technology and strict production to our flatbed trailer.
2>The floor is covered with corrugated sheet metal
3>Good brake effects. Axles are equipped with WABCO emergency brake valve also dual-brake chambers also widen
4>The flatbed container semi trailer painted by advanced painting system, the painting effect can meet Swedish Sa2.5 class marine anti-corrosion standards.
